MS830-MS830A
US$11.50
3
| Current | |
|---|---|
| AC | - |
| DC | 10A |
| Voltage | |
|---|---|
| AC | 600V |
| DC | 600V |
SKU
MS830CBGLO-MS830A-2
23
| Description | Value |
|---|---|
| Safety Rating | CAT III 600V |
| Display counts | 2000 |
| True RMS | No |
| Non-Contact Voltage | No |
| Auto Ranging | No |
| DC current | 10A |
| AC Voltage | 600V |
| DC Voltage | 600V |
| Display Backlight | Yes |
| Auto Power Off | Yes |
| Data Hold | Yes |
| Battery Test | No |
| Overange Indication | No |
| hFE Transistor | No |
| Low Battery Indicator | No |
| Duty Cycle | No |
| Diode | Yes |
| Continuity | Yes |
| Resistance | 200MΩ |
| Temperature | No |
| DAR/PI | No |
| Insulation Test | No |
| Dual Display | No |
| Overload protection | Yes |
| Relative Measurement | No |
| Peak Measurement | No |
| Low Pass Filter | No |
| Sound & Light Warning | No |
| Low Impedance | No |
| Bar Graph | No |
| Analysis Software | No |
| DWELL Test | No |
| TACH Test | No |
| Logic Level Test | No |
| Retractable Tip | No |
| Double Molding | No |
| Work Light | No |
| Frequency | 400Hz |
|
Spec |
Range |
Accuracy |
|
Resistance |
200Ω, 2KΩ, 20KΩ, 200KΩ |
±(1.0%+5) |
|
20MΩ |
±(1.2%+8) |
|
|
200MΩ |
±(5.0%+10) |
|
|
DCV |
200mV, 2V |
±(0.5%+3) |
|
20V, 200V |
±(0.8%+3) |
|
|
600V |
±(0.8%+5) |
|
|
ACV |
200V, 600V |
±(1.0%+10) |
|
DCA |
200uA, 2mA, 20mA |
±(1.0%+5) |
|
200mA |
±(2.0%+5) |
|
|
10A |
±(3.0%+5) |
- Electrical troubleshooting
- Circuit testing
- Automotive diagnostics
- HVAC testing
- General-purpose electrical measurements
| Description | Value |
|---|---|
| Certificate | RoHS, CE, UKCA, EAC |
| Power Supply | 1.5V*2 AAA Battery |
| Product Size | 133*71*47mm |
| Color Box | 112*54*155mm |
| Carton Box | 570*335*250mm |
| Carton included | 40 |
