DCMA5

DCMA3

US$99,999.00

AC Voltage

AC Current

DC Voltage

DC current

Resistance

Capacitance

Frequency

Continuity

Display Backlight

Data Hold

Current
Current
AC	400A
DC	No

Voltage
Voltage
AC	600V
DC	600V

SKU

DCMA3

Information
Description	Value
Safety Rating	CAT III 600V
Display counts	2000 count
Auto Ranging	No
Jaw Size	Ø27mm
True RMS	No
AC Voltage	600V
AC Current	400A
DC Voltage	600V
DC current	No
Non-Contact Voltage	No
Resistance	20MΩ
Capacitance	No
Frequency	No
Duty Cycle	No
Diode	No
Continuity	Yes
Display Backlight	Yes
Work Light	No
Data Hold	Yes
MAX/MIN/AVG	NO
Relative Measurement	No
Bar Graph	No
Insulation Test	No
Low Pass Filter	Yes
Low Impedance	No
Dual Display	No
Peak Measurement	No
Auto Power Off	No
Temperature	No

ACV	Ranges	200V~600V
	Resolution	100mV
	Input impedancy	1MΩ//<100pF
	Overload protection	600V RMS
	Conversion type	RMS
DCV	Ranges	200V~600V
	Resolution	100mV
	Input impedancy	10MΩ
	Overload protection	600V RMS
ACA	Ranges	40A/200A/400A
	Resolution	0.1A/0.1A/1A
	Overload protection	600A
	Conversion type	RMS
OHM	Ranges	200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ
	Resolution	0.1Ω/1Ω/10Ω/100Ω/1kΩ/10kΩ
	Overload protection	600V RMS
Continuity Test	Threshold	less than 20Ω
Continuity Test	Indicator	Buzzer

General
Description	Value
Certificate	CE, UKCA
Power Supply	2×1.5V AAA / 150h Alkaline
Accessories	Test leads, ZnC battery, manual, carrying case.
